Insulation Laminated XPE Polyethylene Foam For Shoe Insoles And Midsoles
Product Details:
| Place of Origin: | Made in china |
| Brand Name: | EkkoFlex |
| Certification: | ROHS,REACH,UL-94 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3000㎡ |
|---|---|
| Price: | $0.18-1.89/㎡ |
| Packaging Details: | poly bag or customized |
| Delivery Time: | 7-14 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000000m per month |
|
Detail Information |
|||
| Product Name: | Insulation Laminated XPE Polyethylene Foam For Shoe Insoles And Midsoles | Material: | Cross-linked Polyethylene Foam |
|---|---|---|---|
| Density: | 28~200kg/m³ | Production Process: | Compounding-Extrusion-Foaming |
| Temperature Resistance: | -40℃ To 80℃ | Thickness: | 3~15mm(single Layer) To 100m(multilayer) |
| Advantage: | Thermal Insulation, Heat Insulation,Insulated | Application: | Building & Construction |
| Width: | 300-1800mm | Cell Structure: | Closed Cell Foam |
Product Description
Insulation Laminated XPE Polyethylene Foam For Shoe Insoles And Midsoles
Insulation Laminated XPE Polyethylene Foam is engineered for shoe insoles and midsoles, combining cushioning with thermal efficiency. Its closed-cell structure provides superior shock absorption, reducing foot fatigue during long walks or sports. The laminated design enhances durability, resisting compression and maintaining shape over time. Ideal for winter footwear, it insulates against cold surfaces while wicking away moisture to keep feet dry. In athletic shoes, it improves energy return and arch support, boosting performance. Lightweight and flexible, the foam conforms to foot contours, making it suitable for custom orthotics and premium footwear. Perfect for outdoor boots, running shoes, and casual wear, it balances comfort, warmth, and long-term durability.
Specifications:
|
Test item |
Items |
|||||||
|
5 Times |
8 Times |
10 Times |
15 Times |
20 Times |
25 Times |
30 Times |
35 Times |
|
|
Density (kg/m3) |
200±30 |
125±15 |
100±10 |
66.7±8 |
50±6 |
40±4 |
33.3±3 |
28.6±2 |
|
Shore Hardness |
60~70 |
50~60 |
45~50 |
35~45 |
30~35 |
25~30 |
18~25 |
13~18 |
|
(°) |
||||||||
|
Water absorbtion (23℃±2℃,24h)g/cm2 |
≤0.02 |
≤0.02 |
≤0.03 |
≤0.03 |
≤0.04 |
≤0.04 |
≤0.05 |
≤0.05 |
|
Heat conductivity |
≤0.092 |
≤0.082 |
≤0.072 |
≤0.062 |
≤0.053 |
≤0.047 |
≤0.041 |
≤0.038 |
The difference between XPE foam and IXPE foam
|
IXPE foam Physical crosslinked polyethylene foam or Irradiation crosslinked polyethylene foam Material PE--Extrusion--Vertical foaming--IXPE foam |
XPE foam Chemically crosslinked polyethylene foam Material PE--Extrusion--Horizontal foaming--XPE foam |
|
|---|---|---|
|
Full name |
||
|
Production |
||
|
Difference |
Compared with XPE foam, IXPE foam has more delicate cellular,more smooth and flat surface,more excellent mechanical performance |
|
|
Color |
Black ,White,Grey and customization |
|
|
Density |
25-200kg/m3 |
|
|
Thickness |
3-15mm(single layer) to 100mm(multilayer) |
0.5-12mm(single layer) to 100mm(multilayer) |
|
Material |
LDPE(Low density polyethylene) |
|
|
Length |
No limited |
|
|
Width |
300-1800mm |
|
|
Supplied form |
Foam roll, Foam sheet, Foam block, ESD PE foam, PE foam with adhesive, PE foam with aluminum foil |
|
|
Optional service |
Laminating, Cutting and Adhesive coated |
|
|
Application |
HVAC system&Airconditioning,Packaging, Building&construction,Sports&Leisure, |
Foam tape,Floor underlayment,Sports&Leisure |
Applications:
Construction and Engineering Materials:
1) Roof insulation/heat insulation/waterproof/road/airport runway/culvert/bridge buffer and heat shrinkable materials
2) Floor/wall thermal insulation, sound insulation and moisture-proof/ground waterproof and shock-proof
3) Pipe insulation, ventilation pipe insulation and outdoor building protection projects
Culture&Sports:
School teaching materials, children's toys, sporting a variety of mattress,surfboard, swimming with life jackets, float and cushioning materials;kitchen sink mat, bath cap and slippers, hats
Shockproof packaging:
TV/refrigerator/household appliance packaging and AC products/electronic instruments/office supplies packaging
FAQ:
Q1:Is XLPE foam recyclable?
Due to it is crosslinked and close cell, it is hard to recyclable. But the wasted pe foam could be reused again, like to be remade
to be mattress, underlay, furniture filling etc
Q2:Does your foam work with adhesives?
Our foam does work well with adhesives. PE foam tape is one of the foam application
Q3:Can you do custom design?
Of course,Color,Logo,Size,Pattern and Materials all could be customized, we have the professional technical staffs.
Q4:What is the difference between polyethylene and polyurethane foam?
Polyethylene is a firm, closed-cell foam.It is also sometimes used as a top layer over softer foam in order to provide better footing while the lower, softer foam adds some shock absorption. What is polyurethane foam? Polyurethane is a softer, open-cell type of foam that is made in varying degrees of firmness.
