Good Adhesion NBR Rubber Foam , Nitrile Butadiene Rubber Foam Self Adhesive
Product Details:
| Place of Origin: | Made In China |
| Brand Name: | EkkoFlex |
| Certification: | ROHS,REACH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3000㎡ |
|---|---|
| Price: | $0.8-1.89/㎡ |
| Packaging Details: | poly bag or customized |
| Delivery Time: | 7-14 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000000m per month |
|
Detail Information |
|||
| Product Name: | Good Adhesion Propeties Nitrile Butadiene Rubber Foam Self Adhesive | Material: | Cellular NBR Sponge Rubber |
|---|---|---|---|
| Cell Structure: | Closed Cell Foam | Type: | Rubber Foam Sheet Roll Sheet Strip Tube |
| Feature: | Soft, Cold Resistance, Fire Retardant, Waterproof | Tearing Power: | 2.76N/cm |
| Application: | Air Conditioning,Construction,Automotive,Electronics | ||
| Highlight: | self adhesive nbr rubber foam,nitrile butadiene rubber foam oem |
||
Product Description
Good Adhesion Propeties Nitrile Butadiene Rubber Foam Self Adhesive
Nitrile closed cell sponge NBR rubber is an excellent gasket material for sealing applications that require oil and UV resistance.
Also resistant to vegetable oil, animal oil, and mineral oil, gasoline, diesel and other aliphatic and aromatic hydrocarbons. Closed Cell oil resistant Nitrile Sponge Rubber can handle temperatures ranging from -40°C to +95°C.
Sponge NBR rubber is an excellent material for gasket applications that require a soft compressible material.
Closed Cell Nitrile Rubber is a sponge formulation that is manufactured with a continuous skin on both sides. The skin makes the sponge stronger and more tear resistant.
Even if the skin is punctured or cut, the sheets will not allow passage of air or fluid between cells. These gaskets are highly compressible, resilient, light weight and provide good thermal insulation.
Specification:
1. NBR Rubber Foam Sheet:
| Specification of NBR Sheet | ||||||
| Thickness(mm) | 6TK | 10TK | 15TK | 20TK | 25TK | 30TK |
| Width(mm) | 1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| Length(mm) | 30 | 20 | 12 | 10 | 8 | 6 |
|
Material |
Density±10 |
Hardness |
Tensile Strength |
Ultimate Elongation |
Max Size |
|
NBR/PVC |
55kg/m³ |
|
≥120 Kpa |
≥120% |
2000*1000*30mm |
|
75kg/m³ |
|
≥120 Kpa |
≥120% |
2000*1000*30mm |
|
|
100kg/m³ |
25° |
≥1000 Kpa |
≥100% |
2000*1000*30mm |
2.NBR Rubber Foam Tube:
| Thickness | inches | 1/4“ | 3/8" | 1/2" | 5/8" | 3/4" | 1" | 1-1/4" |
| mm | 6 | 9 | 13 | 15 | 20 | 25 | 30 | |
| ID | Size ID*TK |
Size ID*TK |
Size ID*TK |
Size ID*TK |
Size ID*TK |
Size ID*TK |
Size ID*TK |
|
| mm | inches | |||||||
| 6 | 1/4" | 6*6 | 6*9 | 6*13 | 6*15 | 6*20 | 6*25 | / |
| 10 | 3/8" | 10*6 | 10*9 | 10*13 | 10*15 | 10*20 | 10*25 | / |
| 13 | 1/2" | 13*6 | 13*9 | 13*13 | 13*15 | 13*20 | 13*25 | / |
| 16 | 5/8" | 16*6 | 16*9 | 16*13 | 16*15 | 16*20 | 16*25 | 16*32 |
| 19 | 3/4" | 18*6 | 19*9 | 19*13 | 19*15 | 19*20 | 19*25 | 19*32 |
| 22 | 7/8" | 22*6 | 22*9 | 22*13 | / | 22*20 | 22*25 | 22*32 |
| 25 | 1" | 25*6 | 25*9 | 25*13 | 25*15 | 25*20 | 25*25 | 25*32 |
| 28 | 1-1/8" | 28*6 | 28*9 | 28*13 | / | 28*20 | 28*25 | 28*32 |
| 32 | 1-1/4" | 32*6 | 32*9 | 32*13 | / | 32*20 | 32*25 | 32*32 |
| 35 | 1-3/8" | 35*6 | 35*9 | 35*13 | / | 35*20 | 35*25 | 35*32 |
| 38 | 1-1/2" | / | 38*9 | 38*13 | / | 38*20 | 38*25 | 38*32 |
| 42 | 1-5/8" | / | 42*9 | 42*13 | / | 42*20 | 42*25 | 42*32 |
| 45 | 1-3/4" | / | / | / | / | / | / | / |
| 48 | 1-7/8" | / | 48*9 | 48*13 | / | 48*20 | 48*25 | 48*32 |
| 50 | 2" | / | 50*9 | 50*13 | / | / | / | / |
| 54 | 2-1/8" | / | 54*9 | 54*13 | / | 54*20 | 54*25 | / |
| 57 | 2-1/4" | / | / | / | / | / | / | / |
| 60 | 2-3/8" | / | 60*9 | 60*13 | / | 60*20 | 60*25 | 60*32 |
| 64 | 2-1/2" | / | / | / | / | / | / | / |
| 67 | 2-5/8" | / | / | / | / | / | / | / |
| 70 | 2-3/4" | / | / | / | / | / | / | / |
| 73 | 2-7/8" | / | / | / | / | / | / | / |
| 76 | 3" | / | / | 76*13 | / | 76*20 | 76*25 | 76*32 |
| 80 | 3-1/8" | / | / | / | / | / | / | / |
| 89 | 3-1/2" | / | / | 89*13 | / | 89*20 | 89*25 | 89*32 |
| 102 | 4" | / | / | / | / | / | / | / |
| 108 | 4-1/4" | / | / | / | / | / | 108*25 | 108*32 |
The comparison between EPDM ,NBR and CR foam rubber:
| Comparison of rubber foam performance parameters | |||
| Performance | EPDM Rubber Foam | NBR Rubber Foam | CR Rubber Foam |
| Aging resistance | good | poor | good |
| electrical insulation | very good | poor | poor |
| preservative | good | general | good |
| Impact elasticity | good | general | -- |
| Adhesion properties | poor | good | -- |
| Oil resistance | no | very good | good |
| Wear resistance | good | good | -- |
| Heat resistance | very good | good | good |
| Cold resistance | very good | poor | poor |
| Ozone resistance | good | -- | good |
| Weather resistance | very good | general | very good |
| Flame resistance | no | -- | good |
| Acid resistance | good | good | general |
| Alkali resistance | good | good | good |
FAQ:
Q1:Do you accept customized foam products ?
We have customized production service, we can produce foam products as per client’s requests.
Q2:What’s the kinds of Foam you can provide ?
We are your one stop foam products supplier. We can provide IXPE foam, XLPE foam, EVA foam,EPDM foam,NBR foam,CR foam,PU foam,MPP foam,MTPU foam, PVDF foam and foam products(foam camping mat,foam floating mat, foam wallpaper, car floor mat)
Q3:How many color of foam products you can produce ?
We offer foam sheets in three standard colors: black, white, and grey. However, if you require a different color for your specific application, we are happy to accommodate your request. To ensure that we provide you with the exact color you need, please provide us with the corresponding Pantone code. If you do not have a Pantone code, you can send us a physical sample of the color you require for our production department to analyze. We strive to meet all of our customers' needs and ensure that they receive the high-quality foam products they require for their specific applications.
