12mm XPE Closed Cell Foam Fire Retardant XLPE Sound Insulation Material
Product Details:
| Place of Origin: | Made in china |
| Brand Name: | EkkoFlex |
| Certification: | ROHS,REACH,UL-94 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3000㎡ |
|---|---|
| Price: | $0.18-1.89/㎡ |
| Packaging Details: | poly bag or customized |
| Delivery Time: | 7-14 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000000m per month |
|
Detail Information |
|||
| Product Name: | 12mm XPE Closed Cell Foam Fire Retardant XLPE Sound Insulation Material | Color: | White,Black,Grey Or Customized |
|---|---|---|---|
| Density: | 28~200kg/m³ | Shore Hardness: | 13~70° |
| Texture: | Smooth Or Embossed | Thermal Conductivity: | 0.038-0.092W/m·K |
| Advantage: | Thermal Insulation, Waterproof And Soundproof | Production Process: | Compounding-extrusion-foaming |
| Highlight: | xpe closed cell foam 12mm thick,xpe foam board customized color,12mm thickness xlpe insulation foam |
||
Product Description
12mm XPE Closed Cell Foam Fire Retardant XLPE Sound Insulation Material
XPE/XLPE foam is a chemical crosslinked polyethylene foam, with low density polyethylene resin and a crosslinking agent and foaming agent through continuous foaming and high temperature, XPE is chemically stable, difficult to decompose, odorless and flexible.
- Thermal Insulation/heat insulation
- Waterproof
- Sound Insulation
- Shock Absorption
- Thermal Forming
- Conductice/Anti-static
Specifications:
|
Test item |
Items |
|||||||
|
5 Times |
8 Times |
10 Times |
15 Times |
20 Times |
25 Times |
30 Times |
35 Times |
|
|
Density (kg/m3) |
200±30 |
125±15 |
100±10 |
66.7±8 |
50±6 |
40±4 |
33.3±3 |
28.6±2 |
|
Shore Hardness |
60~70 |
50~60 |
45~50 |
35~45 |
30~35 |
25~30 |
18~25 |
13~18 |
|
(°) |
||||||||
|
Water absorbtion (23℃±2℃,24h)g/cm2 |
≤0.02 |
≤0.02 |
≤0.03 |
≤0.03 |
≤0.04 |
≤0.04 |
≤0.05 |
≤0.05 |
|
Heat conductivity |
≤0.092 |
≤0.082 |
≤0.072 |
≤0.062 |
≤0.053 |
≤0.047 |
≤0.041 |
≤0.038 |
The difference between XPE foam and IXPE foam
|
IXPE foam Physical crosslinked polyethylene foam or Irradiation crosslinked polyethylene foam Material PE--Extrusion--Vertical foaming--IXPE foam |
XPE foam Chemically crosslinked polyethylene foam Material PE--Extrusion--Horizontal foaming--XPE foam |
|
|---|---|---|
|
Full name |
||
|
Production |
||
|
Difference |
Compared with XPE foam, IXPE foam has more delicate cellular,more smooth and flat surface,more excellent mechanical performance |
|
|
Color |
Black ,White,Grey and customization |
|
|
Density |
25-200kg/m3 |
|
|
Thickness |
3-15mm(single layer) to 100mm(multilayer) |
0.5-12mm(single layer) to 100mm(multilayer) |
|
Material |
LDPE(Low density polyethylene) |
|
|
Length |
No limited |
|
|
Width |
300-1800mm |
|
|
Supplied form |
Foam roll, Foam sheet, Foam block, ESD PE foam, PE foam with adhesive, PE foam with aluminum foil |
|
|
Optional service |
Laminating, Cutting and Adhesive coated |
|
|
Application |
HVAC system&Airconditioning,Packaging, Building&construction,Sports&Leisure, |
Foam tape,Floor underlayment,Sports&Leisure |
Applications:
Insulations:
Heating and cooling machines, tanks, reservoirs;central air conditioning,
Vehicle:
Automotive interior decoration, ceiling, dashboard,cover the old boards, coolers, flooring
Construction:
roof, wall insulation, wallpaper,various infrastructure construction materials;anti-frost, shock cushioning material; interior decoration,mattress materials,wall sound barriers
FAQ:
Q1:Is XLPE foam recyclable?
Due to it is crosslinked and close cell, it is hard to recyclable. But the wasted pe foam could be reused again, like to be remade
to be mattress, underlay, furniture filling etc
Q2:Does your foam work with adhesives?
Our foam does work well with adhesives. PE foam tape is one of the foam application
Q3:Can you do custom design?
Of course,Color,Logo,Size,Pattern and Materials all could be customized, we have the professional technical staffs.
Q4:How can I place an order?
1)Tell us the size details and quantity you want to order.
2)We will make PI for you.
3)Checking PI and confirm it for us, we will arrange the production ASAP when the prepayment received.
4)We will take photos for you to confirm and then deliver the goods soon after the balance.
5)Send the Customs Clearance Documents or tracking number to you and track the goods for you until you get it.
