Cold Resistance EPDM Foam Roll Close Cell Rubber Sheet For Gasket And Sealing
Product Details:
| Place of Origin: | Made In China |
| Brand Name: | EkkoFlex |
| Certification: | ROHS,REACH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3000㎡ |
|---|---|
| Price: | $0.8-1.89/㎡ |
| Packaging Details: | poly bag or customized |
| Delivery Time: | 7-14 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000000m per month |
|
Detail Information |
|||
| Product Name: | Cold Resistance EPDM Foam Roll Close Cell Rubber Sheet For Gasket And Sealing | Material: | EPDM Close Cell Sponge Rubber |
|---|---|---|---|
| Cell Structure: | Close Cell EPDM Foam And Open Cell EPDM Foam | Density (Closed Cell): | 110-150kg/m³ |
| Density(Open Cell): | 95-100kg/m³ | Feature: | Heat Resistance Anti-collision Sound Insulation |
| Application: | Adapt To Brake, Bridge Engineering, Water Proof For Roof | Surface: | One Side Or Both Side Adhesive Or Plain |
| Highlight: | cold resistance epdm foam sheet,cold resistance epdm foam roll,EPDM close cell sponge rubber odm |
||
Product Description
Cold Resistance EPDM Foam Roll Close Cell Rubber Sheet For Gasket And Sealing
Closed Cell EPDM Sponge Rubber:
• Light and good tear strength
• Low co-efficiency of thermal conductivity
• Hight-Performance of water absorption
• Due to good cushioning,it can be used as shock absorbing materials
• Excellent weather-resistance.EPDM model sponge showed no change under the Ozon Resistance Test(50pphmx38℃,20% expansion for 72hrs)
Open Cell EPDM Sponge Rubber:
• It is deformed easily by slight force,it recovers slowly when the presure is released.
• Good tear resistance
• Excellent weather resistance and ozon resistance
• Excellent heat resistance
• Good water sealing property.
Specification:
EPDM(Closed cell)Physical Properties:
| Name&Model | Color | Density (kg/m³) |
Hardness (Shore C°) |
Tensile Strength (Kpa) |
Elongation (%) |
Compression Deformation (%) |
Tear Strength (kn/m) |
Size(mm) | Remarks |
| EPDM-9016 | Black | 190±15 | 25°±5 | ≥500 | ≥130 | ≤40 | ≥3.0 | 950*1900*40 | |
| EPDM-9015 | Black | 150±15 | 15°±5 | ≥400 | ≥120 | ≤45 | ≥2.0 | 1000*2000*50 | |
| EPDM-9010 | Black | 130±15 | 10°±3 | ≥350 | ≥120 | ≤35 | ≥1.8 | 1000*2000*50 | |
| EPDM-9008 | Black | 110±15 | 8°±3 | ≥350 | ≥120 | ≤35 | ≥1.8 | 1000*2000*50 | |
| EPDM-WS | Black | 150±15 | 15°±5 | ≥400 | ≥120 | ≤40 | ≥2.0 | 1000*2000*50 | Sulfur free |
| EPDM-GBZ | Black | 250-500 | 30°-50° | ≥800 | ≥130 | ≤20 | ≥5.0 | 900*1800*35 | High density |
| EPDM-GYD | Black | 600-700 | 50°-75° | ≥1200 | ≥90 | ≤10 | ≥8.0 | 600*1200*30 | High hardness |
| EPDM-SMP | Black | 300±25 | 18°±5 | ≥500 | ≥150 | ≤25 | ≥2.0 | 400*500*568 | Double sided crust |
EPDM (Open cell) Physical Property:
| Name&Model | Color | Density (kg/m³) |
Tensile Strength (Kpa) |
Elongation (%) |
Compression Deformation (%) |
Tear Strength (kn/m) |
Size(mm) | Remarks |
| EPDM-10 | Black/Red/White | 100±15 | ≥100 | ≥200 | ≤3.1 | ≥0.5 | 1000*2000*60 | |
| EPDM-10Z | Black/Red | 100±15 | ≥100 | ≥200 | ≤3.1 | ≥0.5 | 1000*2000*60 | Fire retardant |
| EPDM-20 | Black | 85±15 | ≥100 | ≥200 | ≤3.1 | ≥0.5 | 1000*2000*30 |
The difference between EPDM ,NBR and CR rubber foam:
| Comparison of rubber foam performance parameters | |||
|
Performance |
EPDM Rubber Foam |
NBR Rubber Foam |
CR Rubber Foam |
|
Aging resistance |
good |
poor |
good |
|
electrical insulation |
very good |
poor |
poor |
|
preservative |
good |
general |
good |
|
Impact elasticity |
good |
general |
-- |
|
Adhesion properties |
poor |
good |
-- |
|
Oil resistance |
no |
very good |
good |
|
Wear resistance |
good |
good |
-- |
|
Heat resistance |
very good |
good |
good |
|
Cold resistance |
very good |
poor |
poor |
|
Ozone resistance |
good |
-- |
good |
|
Weather resistance |
very good |
general |
very good |
|
Flame resistance |
no |
-- |
good |
|
Acid resistance |
good |
good |
general |
|
Alkali resistance |
good |
good |
good |
FAQ:
Q1:How to get samples ?
Send inquiry to cissy@eco-polyfoam.com, with your details of the foams need, we will check reply in 24 hour.
Q2:What’s the max thickness you can produce ?
We can laminated different thickness layers into one sheet, our max thickness of lamination is 200mm
Q3:Do you accept customized foam products ?
We have customized production service, we can produce foam products as per client’s requests.
