2mm Thick MTPU Porous Foam Material Shock Absorption CO2 Foaming For Camera
Product Details:
| Place of Origin: | Made In China |
| Brand Name: | EkkoFlex |
| Certification: | ROHS,REACH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3000㎡ |
|---|---|
| Price: | $3.34-5.2/㎡ |
| Packaging Details: | poly bag or customized |
| Delivery Time: | 7-14 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000000m per month |
|
Detail Information |
|||
| Product Name: | 2mm Thick MTPU Porous Foam Material Shock Absorption CO2 Foaming For Camera | Material: | Microcellular Thermoplastic Elastomers-MTPU |
|---|---|---|---|
| Thickness: | 0.6-30mm | Structure: | Non- Crosslinked |
| Density: | 0.12-0.22g/cm³ | Normal Size: | 1mm*1400mm*20m |
| Advantage: | Light,Zero VOC | Application: | Shoe Soles |
| Highlight: | 2mm thick mtpu porous foam,2mm thick mtpu foam,shock absorption mtpu foam |
||
Product Description
2mm Thick MTPU Porous Foam Material Shock Absorption CO2 Foaming For Camera
Perforated MTPU is microcellular TPU foam, produced using thermoplastic polyurethane (TPU) as the composition with clean supercritical carbon dioxide as blowing agent to form a large number of microcells in the matrix.
Advantages:
1.High-elastic means no wrinkles occur, it bounces back quickly after being pressed
2. Super light-weight and soft; weight 300g per square meter
3. Excellent tear strength, withstanding tension of 63kg
4. Oil and dirt resistance
5. Environmentally friendly without odor and waterproof.
The use of PUR adhesive for bonding means 0 formaldehyde, 0 phthalates, safety of medical grade MTPU foam could be recycled
Specification:
|
Product name |
White Black TPU Foam CO2 Foaming MTPU New Foam Materia |
|
Color |
White,Black |
|
Density |
0.12~0.18g/cm³ |
|
Thickness |
0.5-30mm |
|
Width |
1.4-1.45m |
|
Surface |
Perforated foamed sheet, Non-perforated foamed sheet |
|
Foaming principle |
Supercritical Carbon Dioxide Technology |
|
Advantage |
Light, Excellent elasticity, High tensile strength,Zero VOC, 100% recyclable, Soft fell, Water resistance |
|
Specification |
1mm*1400mm*20m; 2*1250*1950mm;3*1200*1900mm |
|
Application |
Insoles, Yoga mat, Camera, Garment lettering film, Clothing lining, bags lining, shoes lining,Soles,Protective gear |
|
Test Items |
M-TPU12 |
M-TPU16 |
M-TPU20 |
|
Density |
0.12±0.015 |
0.14~0.18 |
0.18~0.22 |
|
Hardness |
23±3 |
27 |
34 |
|
Tensile Strength |
1.4 |
4 |
4.4 |
|
Elongation at Break |
130 |
320 |
360 |
|
Method A Tear Trouser Test |
20 |
42 |
52 |
|
Method B Tear AngleTest |
90 |
96 |
110 |
|
Ball Resilience |
≥65 |
68 |
66 |
|
Compression Set |
26 |
25 |
23 |
|
Sun Test |
/ |
4 |
4 |
Application:
Fitness Mat Yoga mat
FAQ:
Q1:What supercritical dioxide Co2 foam could we provide?
MTPU foam,MPP foam, M-PVDF foam
Q2:.Do you accept customized foam products ?
We have customized production service, we can produce foam products as per client’s requests.
Q3:Where is our port of loading?
Shekou or Tantian Port in Shenzhen
