Thermal Insulation Extruded Polyethylene Foam For Construction And Insulation
Product Details:
| Place of Origin: | Made in china |
| Brand Name: | EkkoFlex |
| Certification: | ROHS,REACH,UL-94 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3000㎡ |
|---|---|
| Price: | $0.18-1.89/㎡ |
| Packaging Details: | poly bag or customized |
| Delivery Time: | 7-14 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000000m per month |
|
Detail Information |
|||
| Product Name: | Thermal Insulation Extruded Polyethylene Foam For Construction And Insulation | Material: | Cross-linked Polyethylene Foam |
|---|---|---|---|
| Density: | 28~200kg/m³ | Production Process: | Compounding-Extrusion-Foaming |
| Temperature Resistance: | -40℃ To 80℃ | Thickness: | 3~15mm(single Layer) To 100m(multilayer) |
| Advantage: | Thermal Insulation, Heat Insulation,Insulated | Application: | Building & Construction |
| Width: | 300-1800mm | Cell Structure: | Closed Cell Foam |
Product Description
Thermal Insulation Extruded Polyethylene Foam For Construction And Insulation
Thermal Insulation Extruded Polyethylene Foam is engineered for construction and insulation, delivering superior thermal efficiency. Its closed-cell structure minimizes heat transfer, ideal for walls, roofs, and floors to reduce energy consumption in residential and commercial buildings. The foam resists moisture and mold, making it suitable for basements, bathrooms, and exterior cladding. Lightweight and easy to install, it fits seamlessly between joists or studs, eliminating thermal bridges. In HVAC systems, it insulates ducts to prevent condensation and heat loss. Its durability withstands harsh weather, while the smooth surface allows direct installation of finishes. Perfect for sustainable builds, it enhances R-values and complies with energy codes for eco-friendly construction.
Specifications:
|
Test item |
Items |
|||||||
|
5 Times |
8 Times |
10 Times |
15 Times |
20 Times |
25 Times |
30 Times |
35 Times |
|
|
Density (kg/m3) |
200±30 |
125±15 |
100±10 |
66.7±8 |
50±6 |
40±4 |
33.3±3 |
28.6±2 |
|
Shore Hardness |
60~70 |
50~60 |
45~50 |
35~45 |
30~35 |
25~30 |
18~25 |
13~18 |
|
(°) |
||||||||
|
Water absorbtion (23℃±2℃,24h)g/cm2 |
≤0.02 |
≤0.02 |
≤0.03 |
≤0.03 |
≤0.04 |
≤0.04 |
≤0.05 |
≤0.05 |
|
Heat conductivity |
≤0.092 |
≤0.082 |
≤0.072 |
≤0.062 |
≤0.053 |
≤0.047 |
≤0.041 |
≤0.038 |
The difference between XPE foam and IXPE foam
|
IXPE foam Physical crosslinked polyethylene foam or Irradiation crosslinked polyethylene foam Material PE--Extrusion--Vertical foaming--IXPE foam |
XPE foam Chemically crosslinked polyethylene foam Material PE--Extrusion--Horizontal foaming--XPE foam |
|
|---|---|---|
|
Full name |
||
|
Production |
||
|
Difference |
Compared with XPE foam, IXPE foam has more delicate cellular,more smooth and flat surface,more excellent mechanical performance |
|
|
Color |
Black ,White,Grey and customization |
|
|
Density |
25-200kg/m3 |
|
|
Thickness |
3-15mm(single layer) to 100mm(multilayer) |
0.5-12mm(single layer) to 100mm(multilayer) |
|
Material |
LDPE(Low density polyethylene) |
|
|
Length |
No limited |
|
|
Width |
300-1800mm |
|
|
Supplied form |
Foam roll, Foam sheet, Foam block, ESD PE foam, PE foam with adhesive, PE foam with aluminum foil |
|
|
Optional service |
Laminating, Cutting and Adhesive coated |
|
|
Application |
HVAC system&Airconditioning,Packaging, Building&construction,Sports&Leisure, |
Foam tape,Floor underlayment,Sports&Leisure |
Applications:
Construction and Engineering Materials:
1) Roof insulation/heat insulation/waterproof/road/airport runway/culvert/bridge buffer and heat shrinkable materials
2) Floor/wall thermal insulation, sound insulation and moisture-proof/ground waterproof and shock-proof
3) Pipe insulation, ventilation pipe insulation and outdoor building protection projects
Culture&Sports:
School teaching materials, children's toys, sporting a variety of mattress,surfboard, swimming with life jackets, float and cushioning materials;kitchen sink mat, bath cap and slippers, hats
Shockproof packaging:
TV/refrigerator/household appliance packaging and AC products/electronic instruments/office supplies packaging
FAQ:
Q1:Is XLPE foam recyclable?
Due to it is crosslinked and close cell, it is hard to recyclable. But the wasted pe foam could be reused again, like to be remade
to be mattress, underlay, furniture filling etc
Q2:Does your foam work with adhesives?
Our foam does work well with adhesives. PE foam tape is one of the foam application
Q3:Can you do custom design?
Of course,Color,Logo,Size,Pattern and Materials all could be customized, we have the professional technical staffs.
Q4:What is the difference between polyethylene and polyurethane foam?
Polyethylene is a firm, closed-cell foam.It is also sometimes used as a top layer over softer foam in order to provide better footing while the lower, softer foam adds some shock absorption. What is polyurethane foam? Polyurethane is a softer, open-cell type of foam that is made in varying degrees of firmness.
